PRODUCTS

LEAKAGE CURRENT This equipment is designed to offer a fast, safe, and reliable way to measure touch current—whether unweighted, weighted for perception or reaction, or weighted for let-go. It easily handles both DC and AC currents, with a calibrated frequency response from 20Hz to 1MHz (available in Configurations 1, 2, 3, 4, and 6). Built

ASTM F963-17 Toy Safety Compression Test Probe Model F963-04 is a custom-designed probe by Ergonomics, created to meet the Compression Test requirements outlined in Clause 8.10 of the ASTM F963-17 Standard for Toy Safety. This standard helps prevent injuries and fatalities in children by ensuring toys meet strict mechanical and chemical safety guidelines. The probe

Model RNT100 Rain-Test Spray Heads The RNT100 high-quality spray heads are designed for use with test apparatuses in rain and sprinkler tests, as specified in several Underwriters Laboratories (UL) standards. Crafted from durable white Delrin plastic, they are precisely machined to the dimensions shown in the Figure below. Each spray head is a two-piece assembly

Wire Loop For Glow Wire Test Apparatus For Thermocouple Diameter 1.0 mm Model GW11 Features: Wire loop is fabricated from > 77% Nickel and 20 ± 1% Chromium The dimensions of the glow wire loop are compliant with IEC 60695-2-10:2013, Figure 1 The Diameter of the glow wire loop is 4 mm ± .07 mm

Ergonomics design, fabricates, and calibrates an array of impactors that comply with the Hammer Tests required in IEC 60068-2-75:2014. Below is our Model IH1, which complies with Figure A.1 of IEC 60068- 2-75:2014. This impactor is designed and fabricated in our tool and design shop located in the same facilities as our ISO 17025:2107 calibration

Leverage our experience with designing and fabricating a complete impact test system.  Do not waste time trying to figure out all the components required to perform the testing, and eliminate any uncertainty that the test complies with the standard testing requirements.  Ergonomics offers a turnkey solution that can be used for testing immediately upon delivery.

Standard Model Number Description EN 61010-1-2001, Figure 8; IEC 60601 BBA20 2mm hole for thermocouple applications EN 61010-1-2001, Figure 8; IEC 60601-1, Figure 48; IEC 60335; IEC 60950 BPA10 J 335/2-ANCE; UL50E; CSA22.2 No. 94.2 50E GT IEC 60065, 60950 ITB2A 600mm IEC 60068-2-75; IEC 60335; IEC 60598; IEC 60601; IEC 61010 F22.50 length  350 mm,  diameter 50

This 50mm diameter Impact Test Ball weighing 500 grams is a specially machined ball to test impact resistance according to IEC standards below, as well CSA and UL standards. It is made of chrome-plated steel for durability, and is fitted with an eyelet to facilitate testing for pendulum applications.  Ergonomics can also supply this ball

This probe gauge is used for measuring the protection against access to hazardous parts with a wire. The ball on this model is 35mm in diameter. The 0.5 mm diameter rod is made of stainless steel and the stop face and handle are made of Delrin®. The handles are threaded to accept a force gauge.

The UL Metal Articulated Probe is a standard articulated finger as required by Underwriters Laboratories in many of their standards. It is a jointed test probe specifically designed to test equipment likely to be accessible by children. This probe also applies to more stringent international standards for hazardous parts access, such as IEC 62368-1. The

The UL Metal Rigid Probe is a highly accurate probe made in accordance with all the IEC, UL and International Standards listed below. It is a probe specifically designed to test equipment likely to be accessible by children. This rigid probe is made for forceful insertion where the flexibility of the UL Metal Articulated Probe,

THIS ITEM HAS BEEN DISCONTINUED.

This is a precision probe made in accordance with all IEC standards listed below. It is also used for Canadian and USA standards. It features a palm simulator and a restricted joint movement, which simulates the characteristics of the human hand. The finger is made of stainless steel and the rest of the instrument is

This high quality precision pin probe is supplied in accordance with all IEC standards listed below. The Test Pin Probe, Model TPP15, is used to test for accessibility of small objects and meets IEC, CSA and UL requirements. Ergonomics designs and manufactures these probes in our own facilities, ensuring top quality parts at a competitive

The UIH20 Universal Impact Hammer is the most versatile Impact Hammer available on the market today. It is designed to perform a wide range of impact tests for product durability. Ergonomics ensures this hammer is designed and built to work safely and easily in laboratory and product testing environments. We can also include an ISO

Incline Plane — Model IP01     The Incline Plane, Model IP01, has been developed in accordance with established product safety standards.  Standards such as IEC 60950 and others require product testing at an incline of either 10 or 15 degrees.  Test surface is 900 X 870 mm and close to floor for easy access

The Gasket Test Apparatus is used to check the integrity and endurance of gasket materials used in a Type 2, 3, 3Rm 3S 4, 4X 5, 6, 6P 12, 12K or 13 enclosures. The requirements are listed in clause 8.13.3.3 and is referenced as the Compression Test Gaskets used on enclosures for electrical equipment. The

Ergonomics JN10 – Jet Nozzle IPX 5/6: Precision Testing Made Portable The Ergonomics JN10 – Jet Nozzle IPX 5/6 is engineered for flawless testing across both large and small-scale products, making it the ideal choice when portability and precision matter most. Whether you’re working on-site or in the lab, this powerful, versatile tester ensures compliance

Leverage our experience with designing and fabricating a complete impact test system.  Do not waste time trying to figure out all the components required to perform the testing, and eliminate any uncertainty that the test complies with the standard testing requirements.  Ergonomics offers a turnkey solution that can be used for testing immediately upon delivery.

Safety Test Probe Kit PK950 contains the probes necessary for testing to IEC 60950: JFP10 – Jointed Finger Probe UFP20 – Unjointed (Rigid) Finger Probe TPP15 – Test Pin Probe ITB15 – Ø50mm Impact Test Ball, 500 grams TAP40 – Telecommunications Access Probe This kit includes a case to protect and safely transport your probes.

THIS PROBE HAS BEEN DISCONTINUED. It has been replaced with the HP04. The HP04 is also manufactured to IEC 61010-1, Clause 6.2.3. This probe simulates jewelry to IEC 61010-1, Clause 6.2.3. The probe length is 100 mm long, and is made of white Delrin, The probe diameter is made of steel and is 4 mm

This probe gauge is used for measuring the protection against access to hazardous parts with a wire. The ball on this model is 35mm in diameter. The 4.0 mm diameter rod is made of stainless steel and the stop face and handle are made of Delrin®. The handles are threaded to accept a force gauge.

This probe gauge is used for measuring the protection against access to hazardous parts with a wire. The ball on this model is 35mm in diameter. The 3.0 mm diameter rod is made of stainless steel and the stop face and handle are made of Delrin®. The handles are threaded to accept a force gauge.

This probe gauge is used for measuring the protection against access to hazardous parts. The ball on this model is 35mm in diameter. The 2.5 mm diameter rod is made of Hardened steel and the stop face and handle are made of Delrin®. The handles are threaded to accept a force gauge.

This probe gauge is used for measuring the protection against access to hazardous parts with a wire. The ball on this model is 35mm in diameter. The 1.0 mm diameter rod is made of hardened steel and the stop face and handle are made of Delrin®. The handles are threaded to accept a force gauge.

This probe gauge is used for measuring the protection against access to hazardous parts with a wire. The ball on this model is 35mm in diameter. The 1.0 mm diameter rod is made of stainless steel and the stop face and handle are made of Delrin®. The length has been modified to meet the necessary

This probe gauge is used for measuring the protection against access to hazardous parts with a wire. The ball on this model is 35mm in diameter. The 1.0 mm diameter rod is made of stainless steel and the stop face and handle are made of Delrin®. The length has been modified to meet the necessary

This precision probe is used to test for accessibility according to the latest IEC, CSA, and UL requirements. The probe is made of a Ø 4mm stainless steel rod that is 50mm in length, and connected to a Delrin Handle.

IEC testing of integrity of enclosure seams.

These test probes are safety requirements for the use of saws, as per the standards defined below. These precise probes are fabricated to confirm saw teeth blades are not in any proximity of the guards or the operator at any time. These probes also ensure it is not possible to touch any dangerous moving parts

This probe has been discontinued and has been replaced with the HP03. The HP03 is also manufactured to IEC 61010-1, Clause 6.2.4. This probe simulates jewelry to IEC 61010-1, Clause 6.2.4. The probe length is 100 mm long, and is made of white Delrin, The probe diameter is made of steel and is 3 mm

The Impact Test Ball is a specially machined ball to test impact resistance according to IEC, CSA and UL Standards.

This 50mm diameter Ball Accessibilty Probe is a specially machined assembly to test impact resistance and accessibility  according to IEC standards below, as well CSA and UL standards. This assembly consists of three (3) components.  The first item is Ergonomics item ITB15, a 50 mm diameter impact test ball.   The impact ball is connected to

The FWP10 Food Waste Probe is used for checking food waste disposal units. It is used to test to the following standards: IEC60335-2-16, IEC61032 and UL430.

This is a 75mm sphere used for testing kiddie rides and driving simulators according to IEC 60335-2-24, clause 20.2. It is made of aluminum to conserve weight.

This Amusement Machine Probe is a 150mm wooden sphere used for testing kiddie rides and driving simulators according to IEC 60335-2-82, clause 20.2. It is made of wood to conserve weight.

This high quality precision probe, Model UFP20, is supplied in accordance with all IEC standards listed below. It is also used for CSA and UL requirements. The Unjointed Finger Probe is made for forceful insertion where the flexibility of the Jointed Finger Probe, Model JFP10, would be difficult. Ergonomics designs and manufactures these probes in

T4-42 (1000V) TRACKING TEST APPARATUS is intended for determining the degree of protection against formation of conducting paths in solid insulating materials, due to the electric stress and electrolytic contamination of the surface.

T4-41 (600V) TRACKING TEST APPARATUS is intended for determining the degree of protection against formation of conducting paths in solid insulating materials, due to the electric stress and electrolytic contamination of the surface.

Cheesecloth is used for flammability testing per international and USA safety standards.

This pill-sized source of fuel is used for flammability testing of many materials, including Carpets, Floor Coverings, Textiles, Draperies, Furniture, and Children’s Products. It is required by UL product safety standards for furniture, upholstery, clothing and other fabrics. It is fully compliant with UL and Title 16 Code of Federal Regulations (CFR) Parts 1630 and

The Scratch Tester, Model ST10, has been developed in accordance with product safety standards IEC60950 and IEC60065. It is used to determine the effectiveness of insulating coatings on printed wiring boards and anywhere the robustness of coatings is important. The cart is designed to hold the pin at 80°- 85° and the mass provides the

Vitrek AC Hipot Tester. 5KVAC Electrical Safety tester with continuity. Comes with: TL-209, Power Cord, Operating Manual, QTPro-7 45 Day Free Trial, NIST Traceable calibration certificate without data. The goal for the V7X series has been to achieve the unheard of. To provide state-of-the-art performance in a powerful yet compact multi-function hipot tester – and

For abrasion resistance testing. IEC 60950 and 60065

The Base for the Ball Pressure Apparatus supports the Ball Pressure Apparatus during testing. It is made of stainless steel, with a 2mm hole for thermocouple applications. The base complies with all standards requiring the use of a ball pressure apparatus

The Perfect Solution for Automated Multi-Conductor, Multi-Point Hipot Testing. Features & Benefits • High Voltage Ratings to 3KV, 7KV, 10KV or 15KV • High Current Ratings to 40 Amps • Reduces hazardous operator exposure to high voltage • Improves test quality, consistency and repeatability • Enhances end product quality and reliability • Up to 64

Vitrek built the 95X series from the ground up with DSP technology—to bring you the safest, fastest, most capable, feature rich hipot testers available. The 95X series combines high output power, with a wide range of AC & DC voltage outputs and extremely low leakage current measurement. Then we added a 4-wire milli-ohmmeter with dynamic

Field Detector FD10 is a 3-axis magnetic field meter dedicated to evaluate and verify compliance to occupational exposure limits stated by EU Directive 2013/35 or other limits stated by national laws and regulations or international standards. With the frequency range from 10 Hz to 400 kHz you will cover applications like: Electric power production and

Conforms to ANSI C101.1-1986 “Leakage Current for Appliances” and UL safety standards.

Special purpose AC/DC multimeter, true RMS readings, in accordance with IEC, ANSI and UL guidelines

Water Spillage Apparatus for testing refrigerating appliances. It consists of the vessel, removable bridge support, release pin, and displacement block.

Single Band Magnetic Field Meter Frequency range 5 Hz – 400 kHz Dynamic range 10 nT – 10 mT or 100 nT – 100 mT True RMS and real time spectrum analysis.

Used in IEC 60950 series standards. Recommended to be used with the swivel adaptor G1018-1

Used with force gauges and test fixtures to achieve proper alignment. It relieves stresses to the gauge. Can be used with MGP30 and MGP800 and all gauges having the same threads.

Delrin® disc for testing to IEC 60950.

IEC testing of rigidity of enclosures. IEC 61010 Used with force gauges and other applications.

The WT3-201 wire crimp pull tester is designed to measure the pull-off force of crimped wire and tube terminations. An ergonomic lever allows for easy application of up to 200 lbF (1,000 N) of crimp pull force. Adjustable wire terminal grip contains multiple slots for wire diameters up to AWG 3 (0.25 in [6.3 mm]).

The cord set or plug with mains cord are subjected to a flexing test to control how much the bending movement of the cord influences the electrical and mechanical connection.

The Torque/Withdrawal Tester, Model TWT10, has been developed in accordance with product safety standards IEC60950, IEC60335-1, UL and other safety test standards. It is used to determine the effectiveness of strain reliefs. Specifications: Force Gauge: Model M2-50 Range: 0 to 250N Resolution: 0.2N Accuracy: ±0.5% Torque Gauge: Model TTO3-12 Range: 0 to 1.35 Nm Resolution:

This torque test is for components with a one-part AS plug design. It measures the actual torque from the plug connection with a balance.

SIH10 Series (0.2 to 1.0 Joule range): The SIH10 series Impact Hammer is designed to perform impact tests for product durability.  This Impact Hammer simulates mechanical impact to electronic products and electrical appliances for one (1) specific energy level, ranging in values from 0.20 Joules to 1.0 Joules. A release mechanism assures a release force

Choose one level between 0.2 to 1 Nm (joules) Made in America

Used to test edges on toys and other products. Required for toy safety testing.

This box contains fifty (50) Tape Caps. The tape caps are constructed to meet the latest revised UL standards. They consist of three (3) pre-assembled tapes on a plastic cap. The cap slips onto the SE400K mandrel for testing. The tape caps are constructed using three (3) layers: one layer of black foam tape, one

The Sharp Edge Tester Kit is used for determining the sharpness of edges of electrical equipment and other consumer products. This kit meets Underwriters Laboratories (UL) standard 1439 and Society of Manufacturing Engineers requirements. It is made of a durable metal (not plastic) housing which fits ergonomically into the palm of the hand. Industry-leading features

The Gauge Set measures creepage and clearance distances, distances through insulation and other spacings.

Measures distances through insulation and other safety-related distances as required by all safety standards.

Used for measuring distances between printed wiring traces, and distances through insulation.

The ESM301 and extended length ESM301L are highly configurable motorized test stands for tension and compression testing applications up to 300 lbF (1.5 kN) for laboratory and production environments.

The ES20 manual test stand is a compact and economical solution for compression and tensile testing of small samples. The use of a hand wheel provides for more precise testing with greater consistency in testing results.

Series TT03 digital torque gauges are designed for clockwise and counter-clockwise torque testing applications in virtually every industry, with capacities from 10 ozFin to 100 lbFin (7 to 1,150 Ncm).

Series 7 professional digital force gauges are designed with a number of sophisticated features for the most demanding tension and compression measurement applications, up to 500 lbF (2500 N).

Series 5 advanced digital force gauges are designed for tension and compression force testing in numerous applications across virtually every industry, with capacities from 0.12 lb to 500 lb (0.5 N to 2500 N).

Series 4 digital force gauges are designed for tension and compression force testing in numerous applications across virtually every industry, with capacities from 0.12 lb to 500 lb (0.5 N to 2500 N).

Series 3 digital force gauges are designed for tension and compression force testing in numerous applications from 0.12 lbF to 500 lbF (0.5 N to 2500 N).

The JFP335-20.2 is one of the new accessibility probes required by IEC 60335-1 clause 20.2 for testing the accessibility of moving parts in appliances.

The JFP335-2-14 is one of the new accessibility probes required by IEC 60335 for testing blenders.  Meets the latest CB scheme requirements.

The NAF2 is one of two new accessibility probes required by UL 60950 for paper shredders.

This high quality precision probe, Model TAP40, is supplied in accordance with all IEC standards listed below. It is also used for CSA and UL requirements. The Telecommunications Access Probe is designed to check for limited access to telecommunications voltages (TNV), mainly encompassing telephone jacks and operator areas. This probe complies with all the standards

As required by Telecordia Standard GR-1089-CORE

The Jointed Children’s Finger Probes are supplied in a set of two. Model JFP32A is a simulation for zero to thirty six month old children. The second probe, Model JFP32B, is a simulation for three to fourteen year old children. These test fingers are used to test for protection against access to hazardous parts with

This high quality precision probe, Model UFP25, is supplied in accordance with all IEC standards listed below. It is also used for Canadian and USA standards. The Unjointed Finger Probe is made for forceful insertion where the flexibility of the Jointed Finger Probe, Model JFP10, would be difficult. Ergonomics designs and manufactures these probes in

IEC and UL testing security of snap-on parts.

For U.S. standards.

Several models to choose from… To test to many IEC standards and UL standards.

The Screw-Base Lamp Gauge is designed to evaluate live parts of intermediate screw-base lamps. It is made of stainless steel. This gauge meets UL 588 standard.

Rubber ball used for dynamic stability testing to UL (USA) standards.

This 2.000 inch diameter Impact Test Ball weighing 535 grams is a specially machined ball to test impact resistance according to International Standards and UL 250. It is made of chrome-plated steel for durability, and is fitted with an eyelet to facilitate testing for pendulum applications.  Ergonomics can also supply this ball without an eyelet

Used for testing to many UL Standards checking access to enamel coated wire.

UL Test for access to enamel coated wire.

The Moving Parts Probe is used in UL 507 to test for hazards from moving parts.

4 coins in one – checks access by US coins. UL Standard

The standard requires rotary power mowers to have protective shields. These shields prevent the operator’s foot from contacting the blade, either under the mower’s deck or in the discharge chute area, when the operator has his or her hands on the mower’s controls. Generally, a shield must prevent a foot probe from entering the path

The Blunt Probe is used in UL 1310 Standard for Class 2 Power Units.
